k3s Cluster on 3 Mini PCs From Zero

You’re About to Run Kubernetes at Home (Buckle Up)

Kubernetes feels like hiring a forklift to move a couch. Technically it works, but your neighbors will have questions. k3s is the smaller machine that still does the job. It’s Kubernetes that fits on hardware you can hold in one hand, and today we’re building a three-node cluster from bare metal.

This isn’t a “deploy to the cloud” tutorial. We’re taking three mini PCs, connecting them with Ethernet, installing k3s, wiring up persistent storage, and deploying a workload that answers on a real IP. No managed control plane. No hand-waving. Just you, three boxes, and the weight of responsibility that comes with running your own infrastructure.

Let’s go.

Why Three Nodes (And What They Don’t Give You)

A single-node cluster is real Kubernetes. One k3s server runs the datastore, the control plane, the kubelet, and the container runtime, and it happily hosts pods. Three nodes buy you two specific things:

• Workload redundancy: kill a worker and the scheduler restarts its pods on the survivors, roughly five minutes later with default tolerations
• Room to spread: three machines with 16GB each beats one machine with 16GB once you start stacking services

Now the part most three-node walkthroughs skip. This build gives you one server node and two agents. The control plane is not redundant. If node-1 dies, pods already running on the other two keep serving traffic, but nothing reschedules, kubectl stops answering, and no self-healing happens until you bring that box back.

Control plane high availability in k3s means three server nodes with embedded etcd, started with --cluster-init, talking to each other on TCP 2379 and 2380. That’s a heavier cluster and a different article. Build this one first, learn where the moving parts live, then promote it. If you want the recovery story before you need it, k3s Backups: etcd Snapshots + Velero covers snapshots.

Mini PCs (Beelink, Minisforum, an old ThinkCentre off eBay) fit this job because they’re cheap, around $200 to $400 each, quiet, and light on power. No fan noise at 2 AM, no power bill that makes you weep. And if one dies, you’ve lost $300 instead of $3,000.

Before You Start: Names, IPs, and Ports

Most people wing this part. Addresses “just happen”, DHCP moves something at the worst possible moment, and the cluster spends a week gaslighting you. Ten minutes of planning buys that week back.

Write this down:

• Cluster CIDR (pods): 10.42.0.0/16, the k3s default, keep it
• Service CIDR (services): 10.43.0.0/16, also default, keep it
• Host network: 192.168.1.0/24, your home LAN
• Node IPs (static):
  • 192.168.1.100: node-1, the server
  • 192.168.1.101: node-2, agent
  • 192.168.1.102: node-3, agent

Why static? Services get stable DNS names inside the cluster, but the nodes find each other by IP. Let those float and you’ll donate an evening to troubleshooting.

Set the hostname first

Kubernetes takes node names from the machine hostname, and renaming a node after it joins the cluster is a chore involving deletion and re-registration. Do it before you install anything:

sudo hostnamectl set-hostname node-1   # node-2 and node-3 on the others

Set static IPs

Ubuntu 26.04 LTS below, adjust for your distro. Check the interface name first, because on Ubuntu Server it’s almost never eth0:

ip -br link

Then write the netplan config:

network:
  version: 2
  ethernets:
    enp1s0:                        # use the name from `ip -br link`
      dhcp4: no
      addresses:
        - 192.168.1.100/24         # .101 and .102 on the other nodes
      nameservers:
        addresses: [1.1.1.1, 9.9.9.9]
      routes:
        - to: default
          via: 192.168.1.1

Netplan wants that file locked down, or it complains every time you touch it:

sudo chmod 600 /etc/netplan/01-netcfg.yaml
sudo netplan apply
ip addr show enp1s0

Open the ports

Skip this and your nodes will join, then act haunted an hour later. k3s needs these reachable between machines:

If you keep ufw enabled, on every node:

sudo ufw allow 6443/tcp
sudo ufw allow 8472/udp
sudo ufw allow 10250/tcp
sudo ufw allow from 10.42.0.0/16
sudo ufw allow from 10.43.0.0/16

Keep 8472 on your LAN only. Port-forward the VXLAN port to the internet and you’ve handed strangers a seat inside your cluster network.

Do all of the above on all three machines. Your 2 AM self will appreciate it.

Installing k3s: The Control Plane (node-1)

SSH into the box at 192.168.1.100. Update it and install the basics:

sudo apt-get update && sudo apt-get upgrade -y
sudo apt-get install -y curl wget git htop

Install the k3s server:

curl -sfL https://get.k3s.io | sh -

That’s it. Wait 30 to 60 seconds. k3s installs itself, bootstraps its datastore (SQLite by default on a single server), starts the control plane, and deploys its packaged components: CoreDNS, Traefik, ServiceLB, metrics-server, and the local-path storage provisioner. Remember that list. Two of those items decide how the rest of this article goes.

Check the node:

sudo k3s kubectl get nodes

NAME     STATUS   ROLES                  AGE   VERSION
node-1   Ready    control-plane,master   2m    v1.36.4+k3s1

Now pull the kubeconfig down to your laptop so you can stop typing sudo k3s kubectl:

# on your laptop
mkdir -p ~/.kube
ssh [email protected] "sudo cat /etc/rancher/k3s/k3s.yaml" > ~/.kube/config
sed -i 's|127.0.0.1|192.168.1.100|' ~/.kube/config
chmod 600 ~/.kube/config

The k3s server certificate already lists the node’s own IP, so swapping 127.0.0.1 for 192.168.1.100 works with no extra flags. Any other name, like a DNS record or a reverse proxy address, needs --tls-san at install time.

Test it:

kubectl get nodes

If you see node-1 Ready, you’re golden. If it hangs, TCP 6443 isn’t reachable from your laptop.

Adding Workers (node-2 and node-3)

Grab the join token from node-1:

sudo cat /var/lib/rancher/k3s/server/node-token

On node-2, install k3s as an agent instead of a server:

curl -sfL https://get.k3s.io | K3S_URL=https://192.168.1.100:6443 K3S_TOKEN=<paste-token-here> sh -

Wait 30 seconds. Repeat on node-3. Then check from your laptop:

kubectl get nodes -o wide

NAME     STATUS   ROLES                  AGE   VERSION        INTERNAL-IP
node-1   Ready    control-plane,master   10m   v1.36.4+k3s1   192.168.1.100
node-2   Ready    <none>                 2m    v1.36.4+k3s1   192.168.1.101
node-3   Ready    <none>                 1m    v1.36.4+k3s1   192.168.1.102

Your terminal shows four more columns after that (external IP, OS image, kernel, container runtime). I’ve trimmed them here, and I do the same to the wide output further down, so the interesting parts fit on the page.

The empty ROLES column on the agents is correct. They run workloads and nothing else. Congrats, you have a Kubernetes cluster. The install was the easy half.

Persistent Storage: Making Data Stick Around

Kubernetes throws your data away by default. Pods die, and poof, the container filesystem goes with them. You need a volume that outlives the pod.

k3s ships the local-path provisioner and makes it the default StorageClass, which is plenty for a home lab. It carves a directory on a node’s own disk. Look at it:

kubectl get storageclass

NAME                   PROVISIONER             RECLAIMPOLICY   VOLUMEBINDINGMODE      ALLOWVOLUMEEXPANSION   AGE
local-path (default)   rancher.io/local-path   Delete          WaitForFirstConsumer   false                  12m

That WaitForFirstConsumer is the detail that trips up every first-time k3s user, so read it twice. A claim does nothing on its own. The provisioner waits until a pod is scheduled, because only then does it know which node’s disk to carve the directory on.

Create a claim:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: test-storage
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: local-path
  resources:
    requests:
      storage: 5Gi

kubectl apply -f test-pvc.yaml
kubectl get pvc

NAME           STATUS    VOLUME   CAPACITY   ACCESS MODES   STORAGECLASS   AGE
test-storage   Pending                                      local-path     8s

Pending here is correct, not broken. Nothing consumes the claim yet. Give it a consumer:

apiVersion: v1
kind: Pod
metadata:
  name: pvc-writer
spec:
  containers:
    - name: writer
      image: busybox:1.37
      command: ["sh", "-c", "echo written by $(hostname) > /data/proof.txt && sleep 3600"]
      volumeMounts:
        - name: data
          mountPath: /data
  volumes:
    - name: data
      persistentVolumeClaim:
        claimName: test-storage

kubectl apply -f pvc-writer.yaml
kubectl get pvc

NAME           STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
test-storage   Bound    pvc-9f3c1a02-4d17-4a3e-9b21-6f0c8d2e77aa   5Gi        RWO            local-path     54s

Read the file back to prove the mount works:

kubectl exec pvc-writer -- cat /data/proof.txt

The real directory sits under /var/lib/rancher/k3s/storage/ on whichever node the pod landed on. Which is also the catch: that volume is pinned to that one disk. Lose the node, lose the data. When you outgrow it, Longhorn vs OpenEBS for k3s Storage walks through replicated block storage.

Clean up before moving on:

kubectl delete pod pvc-writer
kubectl delete pvc test-storage

Your First Real Deployment (On a Port That’s Free)

Time to deploy something boring on purpose: an Nginx web server. If Nginx won’t serve, nothing else will.

First, the trap that eats the classic hello-world walkthrough. k3s installed Traefik for you, and Traefik’s own service is type LoadBalancer on ports 80 and 443. ServiceLB implements that by running a DaemonSet that binds those host ports on every node in the cluster. Point a second LoadBalancer service at port 80 and its svclb pods can never schedule, so the service sits forever with no external IP while curl on port 80 hands you Traefik’s 404.

You have two clean options: put the demo on a free port, or reinstall k3s with --disable=traefik and own port 80 yourself. We’ll take the free port, because Traefik is the ingress controller you’ll want later anyway.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-demo
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx-demo
  template:
    metadata:
      labels:
        app: nginx-demo
    spec:
      containers:
        - name: nginx
          image: nginx:alpine
          ports:
            - containerPort: 80
          resources:
            requests:
              memory: "64Mi"
              cpu: "100m"
            limits:
              memory: "128Mi"
              cpu: "200m"
---
apiVersion: v1
kind: Service
metadata:
  name: nginx-demo
spec:
  type: LoadBalancer
  selector:
    app: nginx-demo
  ports:
    - protocol: TCP
      port: 8080        # 80 and 443 belong to Traefik
      targetPort: 80

Deploy it and watch the pods land:

kubectl apply -f nginx-deployment.yaml
kubectl get pods -o wide -w

NAME                          READY   STATUS    RESTARTS   AGE   IP           NODE
nginx-demo-6c4d8f5fbc-abc12   1/1     Running   0          45s   10.42.1.14   node-2
nginx-demo-6c4d8f5fbc-def34   1/1     Running   0          40s   10.42.0.22   node-1
nginx-demo-6c4d8f5fbc-ghi56   1/1     Running   0          35s   10.42.2.9    node-3

Those pod IPs come out of the cluster CIDR you wrote down earlier, one /24 slice per node.

The scheduler spreads replicas of the same service across nodes when it can, so one pod per box is the usual result on an idle cluster. Now the service:

kubectl get svc nginx-demo

NAME         TYPE           CLUSTER-IP     EXTERNAL-IP                                 PORT(S)          AGE
nginx-demo   LoadBalancer   10.43.12.34    192.168.1.100,192.168.1.101,192.168.1.102   8080:31234/TCP   90s

Every node running a svclb pod gets advertised, which is why all three IPs show up. Any of them answers:

curl -s http://192.168.1.101:8080 | head -4

You get the Nginx welcome page HTML. That’s a real application, on hardware you own, reachable from the couch.

Reaching the Cluster From Somewhere Else

Away from home, tunnel the API port over SSH:

ssh -L 6443:localhost:6443 [email protected]

Then use a second kubeconfig context pointing at https://127.0.0.1:6443. The server certificate covers 127.0.0.1 out of the box, so nothing else changes.

Better long term: put the whole home lab behind a VPN and use the LAN addresses from anywhere. Wireguard VPN Server in Docker gets that running in an afternoon.

Monitoring: Is My Cluster Healthy?

Good news, you already have metrics-server. k3s deploys it as a packaged component, so this works right now with nothing installed:

kubectl top nodes

NAME     CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%
node-1   412m         10%    3218Mi          20%
node-2   180m         4%     1704Mi          10%
node-3   206m         5%     1902Mi          12%

Do not apply the upstream metrics-server manifest on top of this. It collides with the packaged copy, k3s re-applies its own manifest on restart, and the upstream defaults reject the k3s kubelet’s self-signed certificate until you add --kubelet-insecure-tls. If you need a custom build, start the server with --disable=metrics-server and then deploy your own.

To find what’s actually eating the cluster:

kubectl top pods -A --sort-by=memory | head -10

Graphs over time come later, with Prometheus and Grafana.

Common Gotchas

“Pods are stuck in ImagePullBackOff”: your nodes can’t reach the registry, or you hit Docker Hub’s anonymous pull limit. Run kubectl describe pod <name> and read the events for the real error, then authenticate to the registry or run a pull-through cache.

“My LoadBalancer service never gets an external IP”: something already owns that host port, and it’s usually Traefik on 80 and 443. Run kubectl -n kube-system get pods | grep svclb and look for pods stuck in Pending. Move your service to a free port.

“Nodes join, then go NotReady”: check UDP 8472 between the machines, then check the clocks. Run timedatectl on each node and confirm NTP sync, because certificate validation fails on a box that thinks it’s still 2019.

“My PersistentVolumes are all on one node”: yes, that’s local-path behaving as designed. It doesn’t replicate. Move to Longhorn or an NFS-backed StorageClass when the data matters.

“kubectl works on the server but not from my laptop”: TCP 6443 has to be reachable, and your kubeconfig has to name an address that’s in the server certificate. The node IP and 127.0.0.1 are covered by default. Anything else needs --tls-san at install time.

The Path Forward

You have a working three-node cluster. Sensible next moves:

• Ingress: route by hostname using the Traefik that’s already running. Ingress Choices in k3s: Traefik vs ingress-nginx vs HAProxy compares the alternatives.
• Replicated storage: Longhorn, so a dead node stops meaning dead data.
• Real control plane HA: rebuild with three servers and --cluster-init once a single reboot taking out kubectl starts to bother you.
• Monitoring: Prometheus and Grafana for history instead of snapshots.
• GitOps: ArgoCD reconciles the cluster against a Git repo, so your YAML stops living in a random directory.
• Secrets: Sealed Secrets or an external store, so your manifests stop carrying base64 passwords.

None of that is required today. You have a cluster. Deploy things on it. Break them. Read the logs.

Three boxes, network cables, and logs you can actually read. Your 2 AM self thanks you already.

Common Questions

Do three nodes give me high availability in k3s?

No. Three nodes with one server node give you workload redundancy only. Control plane high availability needs three server nodes started with --cluster-init and embedded etcd, reachable on TCP 2379 and 2380. One server node stays a single point of failure regardless of how many agents join it.

Why is my k3s PersistentVolumeClaim stuck in Pending?

Because the default local-path StorageClass uses WaitForFirstConsumer binding. The provisioner waits for a pod to be scheduled so it can create the directory on that pod’s node. Create a pod that mounts the claim and the claim binds within seconds. A Pending claim with no consumer is expected behavior.

Can I expose a LoadBalancer service on port 80 in k3s?

Not while Traefik is installed. The Traefik service claims host ports 80 and 443 on every node through ServiceLB, so a second LoadBalancer service on port 80 never gets its svclb pods scheduled. Pick a different port, or install k3s with --disable=traefik and run your own ingress.

How much RAM does a k3s node need?

The official minimums are 2GB and two cores for a server node, 512MB and one core for an agent. Those leave nothing for workloads. Budget 8GB per mini PC and you can stack a dozen small services before the scheduler starts rejecting pods for lack of memory.

Do I need to install metrics-server on k3s?

No. k3s deploys metrics-server as a packaged component, so kubectl top nodes works on a fresh install. Applying the upstream manifest creates a conflicting deployment that k3s overwrites on restart. Disable the packaged copy with --disable=metrics-server only if you need custom flags.
